New 2026 Honda FOURTRAX FOREMAN 4X4

Pricing Details
MSRP: $8,199
Sale Price: $7,699
Savings: − $500

Trade-In Appraisal
Check Availability


Vehicle Saved!

Vehicle Details

  • Stock #: 6H254
  • VIN: 1HFTE4400TJ200963
  • Mileage: 1
  • Engine: 518cc longitudinally mounted liquid-cooled single-cylinder four-stroke
  • Exterior Color: RED
  • Location: Ontario, Oregon

Dealer Comments

TACKLE EVERY JOB. CONQUER EVERY TRAIL.

Built for hard work and ready for adventure, the FourTrax Foreman 4x4 delivers rugged performance with its powerful 518cc engine and long-travel suspension. Whether handling tough jobs or exploring epic trails, this ATV is your go-to machine for reliability, durability, and all-day capability.

POWERFUL 518cc ENGINE
We gave the FourTrax Foreman a tough 518cc engine that cranks out plenty of horsepower and torque. That enhances the Foreman's overall performance, and also gives your Foreman excellent hill-climbing ability.

SEMI-DRY-SUMP ENGINE DESIGN
Compact and light-weight, the Foreman's overhead-valve, semi-dry-sump design creates an engine that's not only shorter from top to bottom, but one that enhances handling by lowering the center of gravity and increasing ground clearance.

ELECTRONIC DIFFERENTIAL LOCK
When you're in 4WD mode and you need to get the power to both front wheels, just flip the switch on the electronic differential lock to maximize available traction. The vehicle display will tell you when the diff lock is fully engaged.

SWINGARM SUSPENSION
The Foreman 4x4 rear swingarm with its solid axle provides superior capability for towing and hauling. Its long suspension stroke and plush seat let you tackle your favorite trail or the toughest chores in comfort all day long.

FRONT AND REAR CARGO RACKS
The Foreman's racks feature strong steel construction and a large flat area. Better still, they're designed so it's easy to attach and remove cargo boxes and other accessories in our Honda Pro-Connect™ line, adding to your Foreman's versatility.

EASY SERVICE ACCESS
The Foreman's body styling is not only aggressive, it's functional. It features a tank and side covers that come off in one piece and without using any tools. That means quick and easy access to the engine.

COLOR OPTIONS:
• Black Forest Green
• Hero Red
• TrueTimber Atera Camo

WARRANTY:
• One year, transferable, limited

DESTINATION CHARGE: $620

Important Safety Information: Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.

All figures are preliminary and subject to change. Images, where available, are presented as reasonable facsimiles of the offered unit and/or manufacturer stock images. Non-standard options or features may be represented. No guarantee of availability or inclusion of displayed options should be inferred; contact dealer for more details. ©2026 American Honda Motor Co., Inc. -- Powersports Division.


Schedule Test Ride
Get Pre-Approved
Request More Info

Similar Vehicles

Tackle every job. Conquer every trail.

Built for hard work and ready for adventure, the FourTrax Foreman 4x4 delivers rugged performance with its powerful 518cc engine and long-travel suspension. Whether handling tough jobs or exploring epic trails, this ATV is your go-to machine for reliability, durability, and all-day capability.



    Highlighted Features
    • Powerful 518cc engine: Experience unwavering performance with our robust, liquid-cooled 518cc engine, which delivers the power you need off-road and on the job.
    • Front/rear cargo racks: Discover unmatched versatility with our durable steel racks. Equipped with our Pro-Connect system, they enable easy attachment and removal of cargo boxes and accessories, enhancing functionality.
    • Swingarm suspension: The rear swingarm features a solid axle that enhances towing and hauling capabilities. Its long suspension stroke and comfortable seat allow you to tackle your favorite trails and the most demanding jobs with ease all day long.
    • Torque-biasing/locking front differential: With the Foreman’s front differential, you can choose between two-wheel drive, four-wheel drive, and four-wheel drive with a locking front differential.
    Engine
    • Engine Type: 518cc longitudinally mounted liquid-cooled single-cylinder four-stroke
    • Bore And Stroke: 96.0mm x 71.5mm
    • Compression Ratio: 9.5:1
    • Valve Train: OHV; two valves per cylinder
    • Induction: Programmed Fuel Injection (PGM-FI); 36mm throttle body
    • Starter: Electric with optional auxiliary recoil
    Drive Train
    • Clutch: Automatic
    • Transmission: Five-speed manual with reverse
    • Driveline: Direct front and rear driveshafts with TraxLok® and front differential lock
    Chassis Suspension Brakes
    • Front Suspension: Independent double-wishbone; 7.3-inch travel
    • Rear Suspension: Swingarm with single shock; 7.3-inch travel
    • Front Brakes: Dual 190mm discs
    • Rear Brake: 160mm sealed mechanical drum
    • Front Tires: 25 x 8-12
    • Rear Tires: 25 x 10-12
    Dimensions
    • Length: 82.9 inches
    • Width: 47.4 inches
    • Height: 47.8 inches
    • Wheelbase: 50.0 inches
    • Seat Height: 34.5 inches
    • Ground Clearance: 7.5 inches
    • Curb Weight: 635 pounds (includes all standard equipment, required fluids and a full tank of fuel)
    • Turning Radius: 10.5 feet
    • Towing Capacity: 848 pounds
    • Front Rack Capacity: 88 pounds
    • Rear Rack Capacity: 176 pounds
    Other
    • Available Colors: Hero Red, Black Forest Green, TrueTimber® Atera Camo
    • Model ID: TRX520FM1
    • Emissions: Meets current EPA CARB (California) off-road emissions standards.
    • Important Safety Information: Recommended for riders 16 years of age and older. Honda recommends that all ATV riders take a training course and read their owner's manual thoroughly.
